Maintenance Free Design 1000W 24 / 48V Wind Turbine Generator
System For Home
Maintenance Free Design
Innovative two-moving -part system
Typical wind turbine has three moving parts(rotor,head yewing and
mechanical furling),HY Energy replaced mechanical furling by using
advanced electromagnetic and blade aerodynamics braking and take
only two moving parts,which improves generator reliability
dramatically as it has less mechanical failure.
Innovative slip ring design
Wind turbine with typical slip ring design often twists and tangles
the connection cable from generator to controller,which made the
system has to be maintained every few month.HY Energy patented slip
ring design solved this problem completely and made HY wind turbine
with higher reliability and real maintenance free.
1000W 3 Blades Wind Turbine Specifications
| Model No. | HY-1000H |
| Rated Output | 1000W |
| Peak Output | 1200W |
| Rated Voltage(V) | Off-grid:DC24/48 On-grid:DC48/110 |
| Start -up Wind Speed | 2.5m/s or 5.6mph |
| Cut -in Wind Speed | 3m/s or 6.7mph |
| Rated Rotor Speed (RPM) | 750 |
| Rated Wind Speed | 12m/s or 26.8mph |
| System Average Cp. | >=0.36 |
| Rated Charging Current(A) | Off-grid:41.7/20.8 |
| Noise Level | <20dB(5m behind turbine at 5m/s gusting) |
| Kwh/m(monthly avg .V =5.5m/s | 192 |
| Working Temp.RangeºC | From -40ºCto 60ºC |
| Survival Max.Wind | 50m/s or 110mph |
| Over-speed Control | Electromagnetic&blade aerodynamic braking |
| Numble of Blades | 3 |
| Rotor Diameter(m) | 1.96 |
| Swept Area(m²) | 3 |
| Generator Material | Aluminum alloy body & precision stainless steel rotor |
| Blade Material | Reinforced nylon glass-fiber |
| Net Weight | 25kgs |
| Tower Connection | Flange connection or bolt-on clamp |
| Controller Type | MPPT or PWM |
| Applications | Stand alone,wind solar hybrid system etc. |
| Product Life(years) | 15 |
| Warranty(years) | 3 |
| Years on Market | 8 |
| Certificate | ISO9001:2008,CE,RoHS,ETL |
Company Picture:
FAQ
1. How can I know where the wind turbine is the right one for my
house?
A: For more detail information, please kindly send us an E-mail for
check.
2. Where can I buy the wind turbine?
A: Please kindly send us the e-mail and we will arrange our sales
person to reply you.
3. Are you factory or trading company?
A: HY Energy is the manufacturer with more than 16 years in the
field of horizontal axis wind turbine. We devoted to develop the
efficient wind turbine for public. Welcome to pay a visit if
possible.
4. Which payment terms are available?
A: So far, we only accept T/T payment for sample orders and bulk
order.
