400W 12 / 24V Patented Blade Design Small Wind Turbine For Home
Over-speed Controll System
Smart Blade Aerodynamics Braking and Electromagnetic Speed
Limitation.
This power curve generated by wind tunnel testing indicated that
the blade aerodynamics braking system starts to take effect from
14-15m/s wind speed,the rotor RPM is always limited within wind
turbine rated maximum RPM at even higher wind.
Abandoned the traditional failure-prone mechanical furling
system,the blade itself is designed with over-speed braking system
which will generate a reverse reluctant torque to lower the blade
rotation speed so that the blades and generator can be well
protected in higher wind,it solved safety and reliability problems
facing by most small wind turbines.
Combination of Electromagnetic braking and aerodybamic braking
maximizes energy capture by extend turbine's operating speed range
into higher and lower wind speed which are missed by the old style
wind turbine.
400W 5 Blades Wind Turbine Specifications
| Model No. | HY-400H |
| Rated Output | 400W |
| Peak Output | 500W |
| Rated Voltage(V) | DC 12/24V |
| Start -up Wind Speed | 2m/s or 4.5mph |
| Cut -in Wind Speed | 2.5m/s or 5.6mph |
| Rated Rotor Speed (RPM) | 750 |
| Rated Wind Speed | 12m/s or 26.8mph |
| System Average Cp. | >=0.36 |
| Rated Charging Current(A) | 33.3/16.7 |
| Noise Level | <20dB(5m behind turbine at 5m/s gusting) |
| Kwh/m(monthly avg .V =5.5m/s | 70 |
| Working Temp.RangeºC | From -40ºCto 60ºC |
| Survival Max.Wind | 50m/s or 110mph |
| Over-speed Control | Electromagnetic&blade aerodynamic braking |
| Numble of Blades | 5 |
| Rotor Diameter(m) | 1.5 |
| Swept Area(m²) | 1.88 |
| Blade Material | Aluminum alloy body & precision stainless steel rotor |
| Net Weight | 22kgs |
| Tower Connection | Flange connection or bolt-on clamp |
| Controller Type | MPPT or PWM |
| Applications | Stand alone,wind solar hybrid system etc. |
| Product Life(years) | 15 |
| Warranty(years) | 3 |
| Years on Market | 8 |
| Certificate | ISO9001:2008,CE,RoHS,ETL |
Company Picture:
FAQ
1. How can I know where the wind turbine is the right one for my
house?
A: For more detail information, please kindly send us an E-mail for
check.
2. Where can I buy the wind turbine?
A: Please kindly send us the e-mail and we will arrange our sales
person to reply you.
3. Are you factory or trading company?
A: HY Energy is the manufacturer with more than 16 years in the
field of horizontal axis wind turbine. We devoted to develop the
efficient wind turbine for public. Welcome to pay a visit if
possible.
4. Which payment terms are available?
A: So far, we only accept T/T payment for sample orders and bulk
order.
