6000W IP65 Wifi Low Noise Design Wind Solar Hybrid Controller
Inverter For Home
This Inverter is applicable with both on-grid and off-grid PV
systems.It can control the flow of energy intelligently .During
daytime,the PV plants generates electricity which can be provided
to the loads,fed into the grid or charge the battery.The
electricity stored can be released when the loads require it during
the night .Additionally.the power grid can aslo charge the storage
devices via the inverter.
1.Innovative solution for Energy storage
2.IP65 dust-proof and water proof rating
3.Monitoring Inverters freely via computers or mobile phones
4.Charge controller and Inverter integrated
5.45ºC full-load output
6.Fanless low-noise design
7.Intelligent battery management function
8.Capable of being grid-interactive or grid-independent
9.Compatible with both Lead-acid and Li-lon battery
10.More security &performance for same costs
Technical Data
| Product Model | GW5048D-ES |
Max allowed PV Power(W) | 6000W |
Nominal DC Power(W) | 5000W |
Max.DC voltage | 580V |
MPPT voltage range | 125-550V |
Startling voltage | 150V |
Max.DC Current | 11/11 |
No.of DC connector | 2 |
No.of MPPTs | 2(can paralled) |
DC connector | MC4/Phoenix/Amphenol |
Battery Type | Lead-acid or Li-lon |
| Norminal Voltage | 48V |
Max.Discharge Power | 4600W |
Max.Charge Power | 4600W,programmable |
Battery Capacity(Ah) | >=100(depending requirement) |
Charging curve | 3-Stage adaptive with maintenance |
| Charging voltage(V) | 60(configurable) |
| Battery temperature compensation | included(Li-lon) |
| Battery Voltage sense | Integrated |
| Current Shunt | Integrated |
| Norminal AC Power | 4600W |
Max AC Power | 4600/4850/4950/5100W |
Peak power(Back-up) | 1.5*Pnom,10sec |
Max .AC current(A) | 20/21** |
Norminal AC output | 50/60Hz,230Vac |
AC output range | 45-55Hz/55-65Hz/180-270Vac |
AC output (Back-up) | 230Vac +_2%,50Hz(60Hz optional)+-0.2%,THDv<3%(linear load) |
| THDi | <1.5% |
| Power factor | 0.8leading-0.8lagging |
| Grid connection | Single phase |
| Max Efficiency | 97.6% |
| Euro Efficiency | >97% |
| MPPT adaptation efficiency | 99.9% |
| Residual current monitorling unit | Integrated |
| Anti-islanding protection | Integrated |
| DC switch(PV) | Integrated(optional) |
| AC over current protection | Integrated |
| Insulation monitoring | Integrated |
| Grid Regulation | VDE-AR-N4105,VDE0126-1-1,G83/2,G59/3,AS4777.2/.3 |
| Safety | IEC62109-1&-2,AS3100,IEC62040-1 |
| EMC | EN61000-6-1,EN61000-6-2,EN61000-6-3,EN61000-6-4,EN61000-3-11,EN61000-3-12 |
| Dimensions(W*H*D) | 516*440*184mm |
| Weight | 30kg |
| Mounting | Wall Bracket |
| Ambient temperature range | -25~60ºC(>45ºC derating) |
| Relative humidity | 0-95% |
| Max operating altitude | 4000m(>3000m derating) |
| Protection degree | IP65 |
| Topology | Transformerless |
| Standby losses | <8 |
| Cooling | Natural convection |
| Noise emision | <25 |
| Display | LED Light&APP |
| Communication | Wifi;RS485 or Ethernet |
Company Picture:
FAQ
1. Which payment terms are available?
A: Our company accept Telegraphic Transfer (T/T) payment for sample
and bulk order.
2. How long will my order ready?
A: The delivery time is within 5 working days upon the payment
receipt for the sample order.
3. I need the other accessories besides the wind turbine, do you
also provide them?
A: Yes, we can supply not only the wind turbine but also the other
parts of the system. E.g: controller, inverter.
Can you help me to design the system for my home and provide all
accessories?
A: No problem. We can give you professorial technical advice and
design the power system according to your request.
