1000W48V Off Grid Home Wind Turbine Home Wind Generator For Remote
House Home Use
Application:
♦Residential On Grid Power System
♦Residential Off Grid Power System
♦Street Light Power System
♦Monitoring Power System
♦Telecom Power System
♦Wind solar hybrid power system
Special Features:
♦Patented Blade Design
--- Capture maximum power from Wind and operates in amazingly low noise
and minimal vibration;
--Reinforced nylon material makes the blades to have more strength,
flexibility and reliability.
♦Over-Speed Control System--Smart blade aerodynamics braking and electromagnetic speed
limitation
♦Maintenance Free Design--Innovation two-moving-part system more reliability dramatically
♦Light Breeze Start Up
♦Long lifetime --- 15 years design
♦ Light weight, easy for installation
♦Anti-rust & Anti-corrosion
♦Damp-proof & sand-proof
General Description:
HY Energy focused on design production and application of high
performance and reliable small wind turbine products. HYE owns 35
patent designs on wind turbine blades, slip ring, rotor structure,
over-speed controller system etc. Each and every component of HYE
wind turbine is independently designed and manufactured in house.
HYE factory owns advanced wind turbine quality testing equipment
and a strict quality control system, all products will go through
22 quality control processes in factory facility.
1000W Home Wind Generator Specification:
| Rated Output | 1000W |
| Peak Output | 1200W |
| Rated Voltage | Off-Grid: DC24/48V |
| Start-up Wind Speed | 2 m/s or 4.5mph |
| Cut-in Wind Speed | 2.5m/s or 5.6mph |
| Rated Wind speed | 12m/s or 26.8mph |
| Working Temp. range | from -40°C to 60°C |
| Survival Max. wind | 50m/s or 110mph |
| Over speed control | Electromagnetic & blade aerodynamic braking |
| Number of Blades | 5 |
| Rotor Diameter | 1.96m |
| Blade Material | Nylon fiberglass reinforced composite |
| Generator Type | Brush less 3-phase PMA with high performance Neodymium Magnets |
| Net Weight | 28kg |
| Tower Type | self-supporting, guyed, tilt-up tower or rooftop mounting etc. |
| Controller Type | PWM/With low voltage charging function |
| Applications | solar & wind hybrid lighting, off-grid power system etc. |
| Product Life | 15 years |
| Warranty | 3 years (optional 5 years) |
| Years on Market | 6 years |
| Certificate | CE, RoHS, ETL, ISO9001:2008, ISO14001 |
Installation:
Installation on site is simple, mainly including mounting blades on
the hub, securing the hub to the turbine body, installing the
nosecone on the blade hub and mounting wind turbine on the pole.
We will supply you all the components and the installation manual
with the photos, you can follow it step by step.
Package:
By Carton ( 400W-1.5KW: one carton; 3KW: two cartons)
Service:
► Warranty: 3 years, option: 5 years(SKF Bearing)
►Sample order available
► Certificate: CE,UL,ISO9001:2008
►Technical service support
F&A
Q1: Is the system solution always the same? Can I customize one?
No. We have professional teams making solutions for you. Solutions
are mainly customized based on different sunshine time / wind speed
and power consumption.
Q2: Can you provide complete power system or only wind turbine?
Yes, we can supply not only the wind turbine but also all the parts
of the system
Q3: Can you design the power system ?
Yes, we have worked in wind power field for over 16 years, we can
give you professorial
technical advice and accord to your request to design the power
system for you.
Q4: Is our wind big enough for it?
HYE wind turbine starts up at 2m/s, cut-in at 2.5m/s. For the area
whose average yearly wind speed over 2m/s, you can use it.
Q5: I don’t know the wind speed of my area?
Just let us know the location of your city, we can help you to
check.
Q6: Delivery time?
Sample order for 7 days; Bulk order for 20 days
Q7: How about the shipping?
Our Packing of the wind turbine usually in one carton, it can be
ship by express or by sea.
General Description:
HY Energy focused on design, production and application of high
performance and reliable small wind turbine products. HYE owns 35
patent designs on wind turbine blades, slip ring, rotor structure,
over-speed controller system etc. Each and every component of HYE
wind turbine is independently designed and manufactured in house.
HYE factory owns advanced wind turbine quality testing equipment
and a strict quality control system, all products will go through
22 quality control processes in factory facility.
